Merrychef 402s Service & Parts Manual

46
402s Ovens Part. N
o.
32Z3539 Issue 5
APPENDIX 4: Recommended spares lists UK/EC
Part No. Description Qty Unit
First
Aid Kit
Service
Kit
1-5
Ovens
5-50
Ovens
50-100
Ovens
Piece Qty for
600 Ovens
11H0364 HT DIODE PCB ASSY 2 EA 2 2 2 6 12 72
11K0004 RELAY PCB 1 EA 1 1 3 6 36
11M0117 DC VOLTAGE CONNECTOR 10 WAY 1 EA 1 1 1 3 6 36
11Z0298 15 WAY 0.1 RIBBON CABLE ASSY 1 EA 1 1 1 3 6 36
30Z0217 FUSE 1in 10A HRC 5 EA 5 5 5 15 30 180
30Z0231 FUSE HOLDER 1IN (13A) 3 EA 3 3 3 9 18 108
30Z0957 FUSE 1x1/4in 1A HBC (MAINS) 1 EA 1 1 1 3 6 36
30Z1340 FILTER 16A (Threaded) 2 EA 2 2 2 6 12 72
30Z1155 BLOCK TRANSFORMER B0012024 1 EA 1 1 3 6 36
30Z1349 MAGNETRON Toshiba 2 EA 1 2 2 6 12 72
30Z1177 20 AMP LITTELFUSE FLM020 4 EA 4 4 4 12 24 144
30Z1178 30A FUSE HOLDER 4 EA 2 4 4 12 24 144
30Z1230 60HZ TRANS MULTI 208 220 240 2 EA 1 2 2 6 12 72
30Z1233 50HZ TRANS MULTI 208 220 240 2 EA 1 2 2 6 12 72
30Z1331 1.0uF 2500V (50HZ Model) 1 EA 1 2 2 6 12 72
30Z1242 1.1uF 2500V (50HZ Model) 1 EA 1 2 2 6 12 72
30Z1251 0.88uF 2500V (60Hz Model) 2 EA 2 4 2 6 12 72
30Z1294 MICROSWITCH WITH ROLLER 4 EA 2 2 2 6 12 72
30Z1295 MAGNETRON COOLING FAN 1 EA 1 1 3 6 36
30Z1298 CAPACITOR - MOTOR START - 2uF 1 EA 1 1 3 6 36
30Z1299 DISPLAY ASSY + HEADER 1 EA 1 1 3 6 36
SA234 THERMISTOR SENSOR ASSEMBLY 2 EA 2 2 2 6 12 72
30Z1315 THERMISTOR 150MM + LEAD 900MM 1 EA 1 1 1 3 6 36
30Z1318 2 POLE ROUND ROCKER SWITCH 1 EA 1 1 1 3 6 36
30Z1319 MOTOR SPEED CONTROLLER 1 EA 1 1 3 6 36
31Z0186 DOOR SEAL SEALANT - 1 TUBE 1 TUBE 1 1 2 6 12 72
31Z0527 STIRRER COVER - SEALANT 1 TUBE 1 TUBE 1 1 2 6 12 72
31Z1247 MICROSWITCH INTERLOCK SPRING 1 EA 1 1 1 3 6 36
32Z4028 COOL DOWN TRAY 1 EA 2 6 12 72
DV0037 BOTTOM TRIM 1 EA 1 1 2 12
SA273 CONTROL FASCIA ASSY V2.0/2.5 1 EA 1 1 3 6 36
DV0091 SIDE PANEL L/H 1 EA 1 1 2 12
DV0092 SIDE PANEL RH 1 EA 1 1 2 12
DV0305 DOOR SEAL (WIDE) 1 EA 1 1 2 6 12 72
DV0203 SEAL - CERAMIC COVER 2 EA 2 2 2 6 12 72
SA274 CONTROL FASCIA ASSY V3.0 1 EA 1 1 3 6 36
DV0275 RACK V3.0 1 EA 1 3 6 36
DV0492 STIRRER COVER - CERAMIC 2 EA 2 2 2 6 12 72
DV0606 HEATER ELEMENT 220V 5 EA 3 5 5 15 30 180
DV0607 HEATER ELEMENT 240V 5 EA 3 5 5 15 30 180
SA111 DOOR ASSEMBLY ( V2.0, V3.0 ) 1 EA 1 1 2 12
SA208 HOT AIR MOTOR ASSY 1 EA 1 1 3 6 36
SA225 MAINS LEAD ASSY (EU) 4-CORE 1 EA 1 1 2 4 24
SA226 MAINS LEAD ASSY (UK) 3-CORE 1 EA 1 1 2 4 24
SA231 LOGIC BOARD MAIN ASSY V2.0/2.5 1 EA 1 1 3 6 36
SA288 STIRRER MOTOR ASSY 1 EA 1 1 3 6 36
SA260 LOGIC BOARD MAIN ASSY V3.0 1 EA 1 1 3 6 36
SA276 AIR FILTER 2 EA 2 2 2 6 12 72
SA314 CATALYST ASSY UPPER 1 EA 1 1 1 6
SA315 CATALYST ASSY LOWER 1 EA 1 1 1 6
SA329 REAR PANEL 1 EA 1 1 2 12
SA339 GREASE FILTER HOUSING 1 EA 1 1 2 12
SA340 GREASE FILTER CARTRIDGE 1 EA 1 1 2 3 18
