5.3.5.3. Trigger-Follow Operating Mode
The Trigger-Follow operating mode only serves for applying the switch-on pulse of the control signal
from the camera system.
Switching on the Trigger-Follow operating mode:
Highlight the required M=Light LED.
Select Trigger Input.
Slide the Pulse period slide control to > 0.
Adjust the required number of pulses per trigger process.
Select the required period duration (Pulse period
[µs]
) or the required frame rate (Pulse period
[fps]
).
Adjust the required pulse duration (Pulse width
[µs]
).
Adjust the required pulse delay (Pulse delay
[µs]
).
Adjust the required intensity for the switch-on duration between 1 and 255% (Power).
Press Send.
You have switched on the Trigger-Follow operating mode. The highlighted M=Light LEDs are
now controlled in accordance with the selected parameters, depending on the corresponding
trigger signal pending at the input of the M=Light LED.
