Software
Operating the Software
8LE-D23_BA_E
20.03.2015
43
/
58
Code
Description
Light2Name=Right
Name of the second M=Light LED in group 2
SwitchCount=1
Number of switches in group 2
Switch1=0x2
Address of the first switch in group 2
Grouping the M=Light LEDs in M=Light Explorer
 Open the example_Groups.ini file from the directory c:\Program Files (x86)\Messring\MLight and
adjust it in accordance with the grouping settings of the M=Light LEDs in your installation.
 In the case that you have NOT installed any switches, enter 0 for the SwitchCount.
 If switches are installed, adjust the address of the switches as necessary.
 Adjust the M=Light LEDs, groups, and addresses in accordance with your installation.
 Save the adjusted file in the same directory using the file name Groups.ini.
 Restart M=Light Control.
 Re-connect the M=Light LED using Connect.
 The groups are now displayed in the M=Light Explorer in the same way as is defined in the
Groups.ini file.
