Operating the Software
Software
42
/
58
20.03.2015
8LE-D23_BA_E
5.3.7.1. Grouping the M=Light LEDs in M=Light Explorer
After installation of M=Light Control, NO groups are defined yet. In M=Light Explorer all M=Light
LEDs connected to the system are listed one after the other.
If you perform regular parameterization of a certain group of M=Light LEDs, it is meaningful to
group this array in order to be able to perform parameterization simultaneously for the entire group.
It is also possible, to assign one M=Light LED to several different groups at a time.
In the c:\Program Files (x86)\Messring\MLight\ directory, there is a file example_Groups.ini with the
following contents:
Code
Description
[Config]
GroupCount=2
Number of groups that are defined
[Group1]
Serial number of the group
Name=Block
Name of the group [Group 1] as it is indicated in M=Light Control
LightCount=2
Number of M=Light LEDs in group 1
Light1=0x01
Address of the first M=Light LED in group 1
Light1Name=Left
Name of the first M=Light LED in group 1
Light2=0x07
Address of the second M=Light LED in group 1
Light2Name=Right
Name of the second M=Light LED in group 1
SwitchCount=1
Number of switches in group 1
Switch1=0xFF
Address of the first switch in group 1
[Group2]
Serial number of the group
Name=Film pit
Name of the group [Group 2] as it is indicated in M=Light Control
LightCount=2
Light1=0x0A
Address of the first M=Light LED in group 2
Light1Name=Left
Name of the first M=Light LED in group 2
Light2=0x3A
Address of the second M=Light LED in group 2
