Meta System EasyCan Digital User Manual

24
When programming is  nished the selections made can be checked again and even changed if wanted by returning
to function no. 1
To go from function no. 11 to no. 1, press the key for 3 seconds; 1 Beep signals return to function no. 1.
FUNCTION DESCRIPTION
1
ARM./DISARM.
FLASH
YES
OFF
NO
1
Buzzer rings during activation
and deactivation of the alarm
2
HORN
FLASH
CONTINUOS
OFF
ALTERNATING
2
It allows to control a horn or pager relay
with a continuous or alternating command
3
DELAYED
CURRENT
DROP
FLASH
YES
OFF
NO
3
It renders operative the protection for current
absorption on the vehicle
4
SENS.
FLASH
HIGH
OFF
STANDARD
4
It allows to vary the sensitivity of the
volumetric protection
5
BLINKER ARM./
DISARM.
FLASH
YES
OFF
NO
5
Blinker working during activation
and deactivation of the alarm
6
PASSIVE
ARMING
FLASH
YES
OFF
NO
6
It automatically activates the engine
block protection
7
PASSIVE
ARMING
+ ALARM
FLASH
YES
OFF
NO
7
It automatically activates the engine block protection
and the alarm part, disabling the ultrasounds
8
DOOR
PROTECTION
FLASH
DERIVATE
OFF
CONTINUE
8
It determines whether or not just the one
alarm cycle is executed with a Doors,
Boot and Bonnet alarm stimulation
9
ANTI
CAR
FLASH
YES
OFF
NO
9
If it is ON it protects the vehicle in the case of
unauthorised use, triggering an alarm cycle and
making it impossible for the engine to be started
again
10
BLINKER
FLASH
OFF
10
It determines whether the Blinker is
controlled by means of power on the lamps
or on the push button of the car blinkers
11
CONTROL
OF
BLINKER
SWITCH
FLASH
CONTINUOS
OFF
SINGOLE
IMPULSE
11
It determines whether the Blinker push
button is controlled by means of a
continuous signal or with a single pulse
+15
ON
X 4
X 4
MAX.
5 SEC.
MAX.
5 SEC.
ACCES TO THE
OPERATING
MODE
TABLE
= 4 BEEP
+15 OFF
SPEED
FLASH
+ 15 ON
+ 15 OFF
SPEED
FLASH
+15
ON
EXIT
OFF
+15 ON
1 BEEP
RE-CHECK/
REPROGRAMMING
CUSTOMISING THE OPERATING MODES
The available operating modes are listed in the following table. The factory settings are in bold type and the possible
alternatives are in plain text.
To change the factory programming, going from line “A” to line “B” of the table (or vice versa) proceed as follows:
NOTE: Passage, via +15 panel, from line “A” to line “B” is indicated by 1 Boop and by 1 Beep from line “B” to line “A”.
Going from one selection to the next using the push button is indicated by the arrows  ashing. The functions that
are not available are shown by the very fast  ashing of the LED.
2 BEEP
2 BOOP
The selectable functions, 1 and 9 contrast with the European Directive 95/56/EC.
(this means that activation is not allowed in all community member states).
X 3 SEC.
