Metabo TS 254 User Manual

16
ENGLISH
1. Getting To Know Your Saw
2. Read first!
3. Safety
4. Installation
5. Commissioning
6. Operation
7. Transport
8. Care and Maintenance
9. Tips and Tricks
10. Available Accessories
11. Repairs
12. Disposal
13. Troubleshooting
14. Technical Specifications
WARNING – Reading the operat-
ing instructions will reduce the risk
of injury.
WARNING - Read all safety warnings
and instructions. Failure to follow all
safety warnings and instructions may re-
sult in electric shock, fire and/or serious
injury.
1. Getting To Know Your Saw
3
1
4
5
6
7
12
13
15
18
17
Rear:
22
23
2
24
Right/hand side:
20
8
16
21
19
11
9
14
10
1 Mitre fence
2 Table extension
3 Blade guard
4 Extraction adapter
5 Extraction hose
6 Rip fence
7 Push stick
8 Table side extension
9 Lock lever for table side exten-
sion
10 Push stick holder
11 Foot/handle
12 On/off switch
13 Handwheel for adjusting bevel
angle
14 Crank for adjusting cutting depth
15 Bevel limitation stop
16 Ratchet lock lever to lock saw
blade tilt
17 Saw blade holder
18 Toolholder
19 Open end wrench
20 Blade guard holder
21 Rip fence holder
22 Mitre fence holder
23 Cable holder
24 Chip ejection
Contents
2. Please Read First!
17028992_10_TS254_EN.fm Original instructions ENGLISH

Metabo TS 254 Specifications

General

Input power	2000 W
Cable length	3.1 m
Output power	1270 W
Idle speed	4200 RPM
Cutting speed	56 m/s
Uncertainty K	3 dB
Blade diameter	254 mm
Sound power level	112 dB
Sound pressure level	99 dB
Cutting height @ 45°	54 mm
Cutting height @ 90°	87 mm
Cutting width @ parallel guide/rip fence (max)	630 mm
Saw blade included	Yes
Placement supported	Tabletop
Material width @ miter fence (max)	200 mm

Weight and Dimensions

Depth	740 mm
Width	750 mm
Height	355 mm
Weight	33400 g
