ENGLISH
27
14. Technical specifications
Voltage V 220 - 240 (1 50/60 Hz)
Wattage
power input P
1
power output P
2
kW
kW
2,00 kW S6 20%
1.27 kW S6 20%
Current draw A 9
Fuse protection min. A 16 (time-lag)
Protection class IP 20
Rated no-load speed (at 230V) rpm 4200
Cutting speed (at 230V) m/s 57
Riving knife thickness mm 2,3
Saw blade
Saw blade diameter (outside)
Saw blade diameter (inside)
Cutting width
max. base body thickness of saw blade
mm
mm
mm
mm
250 - 254
30
2.4
1.6
Depth of cut
with saw blade vertical
at 45° saw blade tilt
mm
mm
0...87
0...50
max. cutting width with rip fence mm 630
max. cross-section width with angle guide mm 200
Dimensions
without machine stand (L x W x H)
with machine stand (L x W x H)
Length of saw table
Width of saw table
mm
mm
mm
mm
740 x 750 x 355
790 x 945 x 850
670/970
715/995
Machine weight with machine stand kg 33.4
Noise emission values according to EN 61029 *
A-sound pressure level L
pA
A-sound power level L
WA
Measuring inaccuracy (K
pA
, K
WA)
dB (A)
dB (A)
dB (A)
83.6
97.9
4.0
* Emission values
Using these values, you can estimate the emissions from this power tool and compare these with the values emitted by other power
tools. The actual values may be higher or lower, depending on the particular application and the condition of the tool or power tool.
In estimating the values, you should also include work breaks and periods of low use. Based on the estimated emission values,
specify protective measures for the user - for example, any organisational steps that must be put in place.
