Metacon-Next FirePro V4 - Potential-Free Contacts; Programmable Input; Photocell

29
4. Potential-free contacts
5. Programmable input
6. Photocell
WARNING
In case of fire, the door will remain open for max. 120 sec. If the safety feature is still activated,
the door will close without the safety feature.
Potential
-
free contacts X6
Connect
X6 features two outputs as potential-free changeover
switches. They can be configured for various functions via
parameters 5.1 and 5.2.
Programmable input X10
Connect
This input can be programmed using parameter 2.6
Photocell X11
A 8 reflection photocell Through-beam photocell
A9 = Transmitter
A10 = Receiver
Through-beam photocell
A11 = Transmitter
A12 = Receiver
