Metacon-Next FirePro V4 - Control Cable Firepro V4

34
8.2 Control cable FirePro V4
Figure 8 FirePro V4 Control cable
Table 5 Components Control cable FirePro V4
Number
Description
1 Cable
2 DES / NES connector
3 Phase connector drive unit
4 Brake connector drive unit
5 Wire-end ferrule
6 DES /NES pin for connector
7 Cable gland
8 Cable inlet rubber
9 Brake connector circuit
10 Motor connector circuit
11 Pin for motor and brake connectors
