43
8.9
Parameter series 5, output settings
5.1
5.2
Function output 1
(terminals X 6)
.1) Switch off
.2) Activated during pre-warning in case of door movement.
.3) Only activated in case of door movement.
.4) Only activated in case of fire alarm or close for power failure, if
this has been selected.
(during pre-warning and door movement).
.5) Only activated in case of fire alarm, smoke alarm or low battery
voltage if the door is moving.
.6) Activated in case of fire alarm/emergency.
.7) Test function for light curtain.
.8) Test function for wireless transfer system on safety edge
protection.
.9) Battery error from power/charger.
1.0) Low battery voltage.
1.1) Safety edge activated/faulty.
1.2) Photocell safety feature activated.
1.3) Error message active.
1.4) End position open reached.
1.5) End position closed reached.
1.6) “Over-close” end position reached.
1.7) No mains power.
1.8) Safety chain motor activated.
1.9) Safety brake or slack cable/pass door contact activated.
2.0) Maintenance.
2.1) Buzzer (activated simultaneously with internal buzzer).
2.2) Activated upon activation fire alarm input 1
(with closed door).
2.3) Activated upon activation fire alarm input 2
(with closed door).
2.4) Activated upon activation fire alarm input 1 + 2
(with closed door).
