SPECIFICATIONS
The Metallisation ARC150/S500-PLC Arc Spray System is designed for anti-corrosion coatings and will
give consistent throughputs with high coating quality.
The following specification covers the standard range of ARC150 Pistol with S500-PLC (ARC150)
Energiser with closed loop current control.
The Pistol Pistol Rating - Max Current: 500 Amps
Dimensions:
WEIGHT
LENGTH
HEIGHT
WIDTH
STAND ALONE
INC. CABLE &
HOSES @ 1.2M
275mm (10.8”)
240mm (9.4”)
102mm (4”)
2.1kg (4.65lb)
5.1kg (11.24lb)
The Energiser (S500-PLC)
Dimensions:
LENGTH
HEIGHT
WIDTH
WEIGHT
900mm (35.4”)
800mm (31.5”)
875mm (34.5”) To Handle
485mm (19.1”)
670mm (26.4”) Wheel to Wheel
291.6kg (644lb)
S500-PLC Energiser Specification:
DESCRIPTION
CHARACTERISTICS
Input Power Requirements
380/415/460 Vac 50-60Hz 3 Phase
Optional Input Power
220V 50-60Hz 3 Phase
Fusing Required
37A @ 460 Vac
40A @ 415 Vac
44A @ 380 Vac
76A @ 220 Vac
84A @ 200 Vac
Max Power Consumption
29 KVA (46Vdc/500A output)
Typical Power Consumption
16 KVA (Zinc 26Vdc/500A output)
22 KVA (Aluminium 35Vdc/500A output)
Duty
0-500 AMPS @ 100% Duty Cycle
Output Voltage
0-49 Vdc Switched High/Low & 1 – 5
(Nominal Spray Voltage 19 to 44Vdc)
Air Requirements
1.5m³ /min @ 5 bar (53cfm @ 72.5 psi)
Power Factor
0.85 Lag
Auxiliary Circuits
110Vac and 24Vdc
Pressure Switch Setting
30 psi (2.0 bar)
