Page 38 of 48
4.7 Rear Wire Guides - Checking
The Rear Wire Guides may be removed for cleaning or renewal whenever necessary i.e.
when worn.
The Power Supply must be isolated and the wire completely removed from the rear of the
Pistol.
The Rear Wire Guides can then be removed by unscrewing them from the Left and Right
Hand Side Plates.
Clean the Rear Wire Guide as necessary or replace if damaged.
NB: For any further maintenance of the ARC150 Pistol please refer to the ARC150
Pistol Maintenance Manual.
