2.1 System Configurations
Variations of the below standard configurations may be possible. Contact Metallisation to
discuss your specific application requirements.
Standard Configuration – Push/Pull with wire in Drums
Most commonly used for in-house anti-corrosion applications where drums can easily be handled.
Standard Configuration – Push/Pull with wire on MIG reels
Most commonly used for on-site anti-corrosion applications where loading of the smaller MIG reels is
more feasible than using drum material.
STANDARD DRUM SYSTEM PART NUMBERS
PART NO
DESCRIPTION
ARC150-2310D
ARC150 System, 2.3mm, 10m supplies, drum dispense
ARC150-2320D
ARC150 System, 2.3mm, 20m supplies, drum dispense
ARC150-2510D
ARC150 System, 2.5mm, 10m supplies, drum dispense
ARC150-2520D
ARC150 System, 2.5mm, 20m supplies, drum dispense
STANDARD MIG SYSTEM PART NUMBERS
PART NO
DESCRIPTION
ARC150-2310M
ARC150 System, 2.3mm, 10m supplies, MIG dispense
ARC150-2320M
ARC150 System, 2.3mm, 20m supplies, MIG dispense
ARC150-2510M
ARC150 System, 2.5mm, 10m supplies, MIG dispense
ARC150-2520M
ARC150 System, 2.5mm, 20m supplies, MIG dispense
Energiser and push/pull
drive unit
Energiser and push/pull
drive unit
Pistol
Pistol
10m / 20m supplies from wire
drive to pistol
10m / 20m supplies from wire
drive to pistol
3m max.
Wire in drums or
coils
