7
TEROS 54
If installation is not possible,
choose another location.
Soft,
loose soil
Compact,
firm soil
Install using
slide hammer
Choosing the right installation method
Soil
condition
Installed
Predrilling
successful?
No
Predrill hole using
TEROS 54
specific auger
Sensor head
contacts soil?
No
Yes
Yes
Sensor head
contacts soil?
Yes
No
Install using
slide hammer
Figure1 Choosing the right installation method
