METER TEROS 54 - Components Description

24
SYSTEM
COMPLIANCE
EM ISO/IEC 17050:2010 (CE Mark)
3.2 COMPONENTS
The TEROS 54 consists of the probe and a protective cap for the thread of the probe head.
VWC sensor
Temperature sensor
Cable
Probe tip
Probe head
Protective cap
Figure17 TEROS 54 components
The TEROS 54 measures the volumetric water content (VWC) and soil temperature at four
defined depths: 15 cm, 30 cm, 45 cm, and 60 cm. Each depth represents the center point of the
measuring sensors. At every measuring depth, the TEROS54 is equipped with four independent
VWC sensors for a 360° measurement (Figure19). Because the TEROS 54 is equipped with four
sensors per depth, it gives an accurrate representation of the soil at that depth.
