TEROS 54
For the best output, the measured values of all four sensors are calculated together. If the
measurement at one of the four sensors is disturbed, for example, because a root or a stone
interferes with the sensor, the 360° measurement coverage of the TEROS 54 compensates
for this. In this case the other three sensors provide correct data.
The most accurate measurement results are obtained very close to the TEROS 54 shaft in
each area between the wings. As the distance from the shaft increases, the strength of the
sensors also decreases. The measuring volume is approximately 300 cm³ per depth.
Detail View
8.0 cm (3.1 in)
7.0 cm (2.8 in)
Figure18 Volume of influence
