22
SYSTEM
Connector Size
3.50 mm (diameter)
14.4 mm (diameter M12)
Connector Types
Stereo plug connector or stripped and tinned wires
4-pin M12 connector or stripped and tinned wires
Conductor Gauge
Stereo Plug
M12 Plug
22-AWG / 24-AWG ground wire
22-AWG
ELECTRICAL AND TIMING CHARACTERISTICS
Supply Voltage (power to ground)
Minimum 4.0 VDC
Typical NA
Maximum 24.0 VDC
Digital Input Voltage (logic high)
Minimum 2.8 V
Typical 3.6 V
Maximum 5.0 V
Digital Input Voltage (logic low)
Minimum –0.3 V
Typical 0.0 V
Maximum 0.8 V
Digital Output Voltage (logic high)
Minimum NA
Typical 3.6 V
Maximum NA
