Send Units
Specifies whether or not the unit type for a given value is sent along with the
value. Set to Yes or No using the appropriate softkey.
Send Eol(End of Line)
Configures the desired character to be sent at the end of an output line.
CR(Carriage Return), Line Feed(LF) or CR &LF can be selected using the
appropriate softkey. EOL can also be set to None.
Field Delimiter
Configures the desired field delimiter(separator) to Comma or Tab. Set to
desired delimiter using the appropriate softkey.
MLX200 9 Pin
Dsub(F)
Description
Switch Device(Footswitch/Buttons/ETC)
RS232 9 Pin
Dsub(M)
1
TRIG_2_IN
SW2 Common
NC
2
RX_IN
2
3
TX_OUT
3
4
TRIG_1_OUT
NC
5
GND
SW1 & SW2 (Normally Open) & Earth
Ground
5
6
TRIG_1_IN
SW1 Common
NC
7
TRIG_3_IN
NC
8
TRIG_2_OUT
NC
9
TRIG_3_OUT
NC
NOTE: If you do not see the Send button( )in your top or softkey toolbar, you may need to enable the display of the
Send button in Desktop settings.
To send measurement data out of the RS232 port.
• Step 1: Produce some feature measurements for sending out of the RS232 port.
• Step 2: Press the Send button to access the position/coefficient selection screen.
• Step 3: Press the desired softkey, or use the touch screen, to choose what to send out of the RS232 port. The
selections you make will be displayed in orange to indicate their selection state.
• Step 4: Press the green check-mark button in the sofkey toolbar to confirm the selection and transmit the data.
