Metra Electronics 95-3302 - Saturn Aura 2007-2009

9
95-3302 DASH DISASSEMBLY
Saturn Aura 2007-2009
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove shifter trim ring.
(Figure A)
Unclip and remo
ve the center con-
sole trim panel, then remove (2)
screws from bottom edge of dash
trim panel. (Figure B)
3
Unclip and remove the key switch
trim ring, then unclip and remove
dash trim panel. (Figure C)
4
5
6
Remove (2) screws securing the cli-
mate controls.
Remove (4) screws securing the radio.
Unplug and remove the radio.
Continue to kit assembly.
2
A
B
C
