95-3302 DASH DISASSEMBLY
Saturn Vue 2006-2007
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Grasp the front edge of the shifter
trim panel and pull outward and
upward.
(Figure A)
2
Squeeze the locking tabs located at
the front edge of the shifter trim
panel together to release the front
edge of the panel from the center
console.
(Figure B)
3
Pull upward on the panel to release
the remaining clips, and remove trim
panel.
4
Remove (4) screws securing storage
pocket and remove pocket.
(Figure C)
5
Unclip and remove center dash trim
panel.
(Figure D)
6
Remove (4) screws securing the
radio. Unplug and remove the radio.
7
Continue to kit assembly.
