95-3302 DASH DISASSEMBLY
Saturn Sky 2006-2009
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove side panel from
driver’s side of dash with door open
and remove (2) 7 MM screws.
(Figure A)
2
Remove (2) 7 MM screws from bottom
edge of panel below steering wheel,
unclip panel and remove panel.
3
Unclip and remove side panel from
passenger side of dash with door
open and remove (2) 7 MM screws
from behind panel. (Figure B)
4
Open the glove box and disconnect
the glove box dampener from the
glove box assembly. Squeeze sides
together to open further. (Figure C)
5
Remove (2) bolt covers from top
edge of glove box frame. (Figure C)
6
Remove (5) bolts from glove box
frame and remove frame. (Figure C)
7
Unsnap and remove climate control
trim panel. (Figure D)
8
Remove (1) screw from lower left
corner of radio trim panel and
unplug connectors to remove panel.
(Figure D)
9
Remove (4) screws securing the
radio. Unplug and remove the radio.
10
Continue to kit assembly.
A
B
C
D
