3
95-3302 DASH DISASSEMBLY
Chevrolet HHR 2006-2010
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove entire panel sur-
rounding radio and a/c controls
including the a/c vents. (Figure A)
2
Remove (8) 9/32” screws securing
radio and a/c control to remove
radio. (Figure B)
3
Continue to kit assembly.
A
B
