95-3302 DASH DISASSEMBLY
Chevrolet Equinox 2005-2006
Pontiac Torrent 2006
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unsnap panel below power window
switch and remove. Note: This
allows you to unplug the window
switch easier. (Figure A)
2
Unsnap and remove entire panel sur-
rounding radio and shifter. (Figure B)
3
Remove (4) 9/32 screws securing
radio. Unplug and remove the radio.
(Figure C)
4
Continue to kit assembly.
A
B
C
