Metra Electronics 95-3302 - Malibu 2004-2007

5
95-3302 DASH DISASSEMBLY
Chevrolet Malibu 2004-2007
Remove (2) 7 MM screws from bot-
tom of glove box then open box and
squeeze sides together to open fur-
ther and remove the remaining (4)
7MM screws. Unclip the black vent
cover under the glove box then unclip
and remove entire glove box assem-
bly. (Figure F)
7
Unclip and remove trim panel sur-
rounding radio and climate controls.
(Figure G)
8
Remove (4) 7 MM screws securing
the radio and (2) 7 MM screws secur-
ing the climate control. Unplug and
remove the radio. (Figure H)
9
Continue to kit assembly.
F
E
G
H
Unclip and remove side panel from
passenger side of dash with door
open and remove (2) 7 MM screws
from behind panel. (Figure E)
6
