10
95-3302 DASH DISASSEMBLY
Saturn Ion 2006-2007
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip radio trim panel. (Figure A)
Unplug connectors from trim panel and
remove panel. (Figure B)
2
Remove (4) screws securing the
radio. Unplug and remove the radio.
3
A
B
Continue to kit assembly.
To Next Page
