Metra Electronics 99-3300 - Kit Assembly Procedures; DIN Mount Radio Provision

99-3300 KIT ASSEMBLY
9
A
B
CD
DIN MOUNT RADIO PROVISION
Cut and remove the shaft supports
from the radio housing. (Figure A)
1
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward. (Figure B)
NOTE: The spacer included with this kit
can be used between the radio and the
DIN cage fror vehicles with shallow
radio cavities if necessary. (Figure D)
2
Slide the aftermarket radio into the
cage until it snaps into place. (Figure C)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
