99-3300 DASH DISASSEMBLY
Chevrolet Blazer/S-10 Pickup,
GMC Jimmy/Sonoma 1998-2002, GMC Envoy,
Isuzu Hombre, Oldsmobile Bravada 1998-2001
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Remove (2) 9/32” hex head screws
from the lower dash trim panel below
steering column.
2
Remove (2) 9/32” hex head screws
from bottom edge of instrument clus-
ter trim panel.
3
Remove (1) Phillips head screw from
above the instrument cluster.
4
Unclip and remove instrument cluster
trim panel.
5
Remove (2) 9/32” hex head screws
securing radio. Unplug and remove
radio.
6
Continue to kit assembly.
