Metra Electronics 99-3300 - Chevrolet Camaro Dash Disassembly

2
99-3300 DASH DISASSEMBLY
Chevrolet Camaro 1997-2002
Dash cavity
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the radio trim
panel. (Figure A)
2
Remove (2) 9/32” hex head screws
securing radio. Unplug and remove
radio. (Figure A)
3
Cut and remove the rear support from
the back of radio cavity. (Figure B)
4
Continue to kit assembly.
A
B
