99-3300 DASH DISASSEMBLY
Chevrolet Corvette 1997-1999
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Using a panel removal tool pry out
on the “Ride Control” switch, unplug
and remove switch.
2
Unclip and remove switch trim
panel.
3
Remove (2) 10 MM hex head bolts
from behind panel.
4
Open center console door and
remove (4) screws from hinge to
remove door.
5
Open ashtray and remove (1) screw
securing ashtray.
6
Remove ashtray and remove (1)
screw from ashtray cavity.
7
Unclip and remove small grill to the
left of the ignition switch.
8
Remove one (1) screw from behind
grill. Unclip and remove dash trim
panel.
9
Remove (2) 9/32” hex head screws
securing radio. Unplug and remove
radio.
10
Continue to kit assembly.
