4
99-3300 DASH DISASSEMBLY
Chevrolet Cavalier 1995-1999
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Remove (3) 9/32” hex head screws
from along top edge inside of glove
box.
2
Remove (2) 9/32” hex head screws
from behind glove box. (Access
these screws thru cutout in rear of
glove box at top left corner.)
3
Remove (1) Phillips head screw from
defroster vent and remove the vent.
4
Remove (1) Phillips head screw from
inside defroster.
5
Unclip and remove the trim panel at
each of dash and remove (1) Phillips
head screw from behind panel.
6
Remove dash pad.
7
Remove (3) Phillips head screws from
top edge of instrument cluster/radio
trim panel. Unclip and remove dash
trim panel.
8
Remove (2) 9/32” hex head screws
securing radio. Unplug and remove
radio.
9
Cut and remove the rear support from
the back of radio cavity. (Figure A)
10
Continue to kit assembly.
