99-3300 DASH DISASSEMBLY
Chevrolet Lumina/Monte Carlo 1995-2001
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove dash trim panel.
(It may be necessary to loosen the
lower dash trim panel below steer-
ing column.)
2
Remove (2) 9/32” hex head screws
securing radio. Unplug and remove
radio.
3
Cut and remove the rear support from
the back of radio cavity. (Figure A)
4
Continue to kit assembly.
