Metra Electronics ELS - Locker Controller ELS & ELS SELECT Technical Manual; Product Description

Page 4
Locker Controller ELS & ELS SELECT Technical Manual
Locker Controller ELS & ELS SELECT Technical Manual
Manufacturer:
Metra inženiring d.o.o.
IOC Trzin
Špruha 19
SI-1236 Trzin, Slovenia
phone:
fax:
web:
+386 1 56 10 740
+386 1 56 10 744
www.metra.si
System:
Metra ELS & ELS SELECT– Electronic Locking Systems
Product Group:
Locker Controller
Types:
 LC16AELKP, LC16AESKP, LC16ELKP, LC16ESKP, LC24ELKP, LC24ESKP, LC32ELKP, LC32ESKP (Keypad)
 LC16AELIS, LC16AESIS, LC16ELIS, LC16ESIS, LC24ELIS, LC24ESIS, LC32ELIS, LC32ESIS (ISO 15693, ISO14443A/B)
 LC16AELLF, LC16AESLF, LC16ELLF, LC16ESLF, LC24ELLF, LC24ESLF, LC32ELLF, LC32ESLF (LF Multitag)
 LC16AELMF, LC16AESMF, LC16ELMF, LC16ESMF, LC24ELMF, LC24ESMF, LC32ELMF, LC32ESMF (Mifare)
 LC16AELSD, LC16AESSD, LC16ELSD, LC16ESSD, LC24ELSD, LC24ESSD, LC32ELSD, LC32ESSD (Skidata)
 LC08 (Locker Controller Extension Module)
Year of Construction:
2008-2011
Declaration of Conformity:
The Metra ELS & ELS SELECT products have been developed, designed
and manufactured in accordance with the EU directive for
Electromagnetic Compatibility (2004/108/EC).
Locker Controller ELS & ELS SELECT Technical Manual [rev.0-030811]
2011 Metra inženiring d.o.o.
All Rights reserved.
No part of this manual may be reproduced in any form or by any means without prior written permission of Metra inženiring d.o.o.
The contents of this manual are subject to change without notice.
All efforts have been made to ensure the accuracy of the contents of this manual, however, should any errors be detected, Metra inženiring would greatly appreciate being informed of
them. Metra inženiring d.o.o. can assume no responsibility for any errors in this manual.
 Product description
Metra Locker Controller is used in different Metra Electronic Locking Systems. Device drives and
monitors Metra Electronic Locks. Up to 16 locks can be connected directly to the unit, with the
possibility to add up to two Extension Modules for 8 additional Electronic Locks each. This enables
configurations for up to 16, 24 or 32 locks, which makes the controller adoptable to many locker
layout configurations. As user interface different system specific Metra user interface devices (e.g.
Display RFID/Keypad/Combo/Touch, Reader Terminal, Reader Terminal Basic, etc.) can be used.
