Locker Controller ELS & ELS SELECT Technical Manual
#
description
#
description
1
Electronic Lock 1
27
Electronic Lock 27
2
Electronic Lock 2
28
Electronic Lock 28
3
Electronic Lock 3
29
Electronic Lock 29
4
Electronic Lock 4
30
Electronic Lock 30
5
Electronic Lock 5
31
Electronic Lock 31
6
Electronic Lock 6
32
Electronic Lock 32
7
Electronic Lock 7
33
Local CAN*
8
Electronic Lock 8
34
Local CAN*
9
Electronic Lock 9
35
BDM Loader
10
Electronic Lock 10
36
Local CAN**
11
Electronic Lock 11
37
Local CAN**
12
Electronic Lock 12
38
BDM Loader
13
Electronic Lock 13
39
COM (Not used)
14
Electronic Lock 14
40
Local CAN***
15
Electronic Lock 15
41
Local CAN***
16
Electronic Lock 16
42
Metra NET Network
17
Electronic Lock 17
43
Power****
18
Electronic Lock 18
44
Power****
19
Electronic Lock 19
45
Emergency open pushbutton
20
Electronic Lock 20
46
Coin acceptor
21
Electronic Lock 21
47
Reader (Not used)
22
Electronic Lock 22
48
Fingerprint module
23
Electronic Lock 23
49
Display
24
Electronic Lock 24
50
I2C (Not used)
25
Electronic Lock 25
51
BDM Loader
26
Electronic Lock 26
52
I2C (Not used)
*NOTE: Local CAN connectors and are internally parallel connected.
**NOTE: Local CAN connectors and are internally parallel connected.
***NOTE: Local CAN connectors and are internally parallel connected.
****NOTE: 12V DC Power connectors and are internally parallel connected.
 Connecting Locker Extension Modules
When Locker Controller without mounting plate is used connect up to two Extension modules by 6
wire flat cable. There are two equivalent connectors on the main electronics board (LC16A) use the
one which suits your connection best.
