Metra Electronics ELS - Appendix

Page 41
Locker Controller ELS & ELS SELECT Technical Manual
Buffer capacity
40 records
Electronic Lock Interface
Up to 16/24/32 El. Locks, 6 wire flat cable, max. length 20m
Dimensions in mm (w/h/l)
100/20/179 main electronics
100/20/89 extension board
171/5/380 mounting plate
Connections
Power, Metra NET Network, Display, Coin acceptor, external
Emergency open push-button,
 Appendix
1
Physical dimensions
Locker Controller
Locker Controller Extension Module
2
Physical dimensions
Mounting rails
3
Physical dimensions
Mounting plate
4
Physical dimensions
Coin Acceptor mounting hole
5
Physical dimensions
Fingerprint module
6
Network schematic
7
Cable installation
8
Device configuration (example 1)
9
Device configuration (example 2)
