Autolab/Electronic load combination
32 | Page
Figure 27 – The output of the electronic load can be plotted and displayed in the Autolab
display window when sampled
Since the measurements are performed without switching the cell switch of the
Autolab on, a warning will be shown during validation (see Figure 28).
The value shown in the Autolab display is only visible during a measurement.
