Autolab/Electronic load combination
6 | Page
Figure 1 – Contour map of the TDI RBL 488
2
– Dynload interface part list
The Dynload interface kit includes the following items:
1. The Dynload interface (see Figure 2).
2. 15 V power supply
3. A 2 m long BNC cable
4. A 50 Ω terminator plug
5. 6 BNC to SMB adaptor plugs
6. 3 SMB shielded cables (1 m)
7. A BNC splitter
A special Dynload interface version suitable for the Electronic loads supplied by
the Japanese brand Kikusui is available on request (see Figure 2). This version is
only suitable for the Kikusui loads.
