Autolab/Electronic load combination
48 | Page
Appendix 1 – Specifications of known electronic loads
The DC and AC conversion settings are specified in Table 2 and Table 3,
respectively.
DAC164 1
Conversion slope
ADC164 1
Conversion slope
33 -3.3 -3.3
132 -13.2 -13.2
300 -30 -30
1000 -100 -100
60 -6 -6
60 -6 -6
60 -6 -6
Table 2 – Overview of the DC settings (to be specified in the Hardware setup) for known
electronic loads
33 0.303 -3.3
132 0.0757 -13.2
300 0.0333 -30
1000 0.0100 -100
60 0.166 -6
60 0.166 -6
60 0.166 -6
Table 3 –Overview of the AC settings (to be specified in the
FRA measurement external
command) for known electronic loads
For information on electronic loads not listed in the Appendix please contact
Metrohm Autolab (info@metrohm-autolab.com).
