30. Set the pacer load to 500 ohm. Connect a pulse generator to the
pacer input. The following values are acceptable:
Parameter Value Max. Deviation
Rate: 80 ppm
±0.5 ppm
Width: 10 ms
±0.3 ms
Amplitude: 20 mA
±1 mA
Energy: 2.0 mJ
±0.5 mJ
31. Set the pacer load to 1000 ohm. Connect a pulse generator to
the pacer input. The following values are acceptable:
Parameter Value Max. Deviation
Rate: 80 ppm
±0.5 ppm
Width: 10 ms
±0.3 ms
Amplitude: 10 mA
±1 mA
Energy: 1.0 mJ
±0.5 mJ
The test is complete!
