Choose a test variant by pressing UP (F2) or DOWN (F3) or
TEST PULSE (F1). Press CANCEL (F5) to cancel selection.
For ‘ECG0’, ‘ECG+’ and ‘ECG-’ see Chapter 6, Control and
Calibration. For ‘A/D-read’, see paragraph 7.3.7, page 7-5.
Memory’ is for factory testing. Also, see paragraph 4.3.5, page
4-3.
11. REMOTE CONTR. (Remote Control) (F4) enables communi-
cation with a PC with test automation software. Required soft-
ware: PRO-Soft QA-40/45.
3.4 Menu and Messages:
Transcutaneous
Pacemaker Mode
1. Startup Screen. The following screen will be displayed for 2
seconds after the QA-45 has been switched on.
2. Main Menu
a. Main Menu Bar (Page 1) - Mode switch in PACE position.
Note
QA-40M has an internally gener-
ated test pulse. The control pulse
is set at 1.2 Joules in the Low
range and 28.5 Joules in the High
range. The test pulse is not a cali-
bration pulse, and should not be
used as an indication of the gen-
eral accuracy of the instrument.
The test pulse is a good control for
testing functions.
6
