7.6 Component Parts
COMPONENT PART TYPE/VALUE QTY. DIAGRAM REFERENCE
PROCESSOR BOARD
Processor board AR-095 1
Microprocessor MC68HC11G5FN 1 IC13
RAM LH5160HD-10L 1 IC16
EPROM 27C010-120 1 IC14
EEPROM X24C16P 1 IC7
PAL PAL. 22V10Z-25PC 1 IC15
D/A converter MX7528KN 1 IC1
Op.amp LM358P 1 IC17
Op.amp LT1013DN8 2 IC2, IC3
V-ref. LM-385Z-2V5 2 IC12, IC18
Timer LMC555CN 1 IC106
Port 74HC05N 1 IC9
Bus driver 74HC541N 1 IC10
Latch 74HC573N 1 ICll
Volt. Regulator LP2951CN 1 IC4
Volt. Converter LT1054CN8 1 IC5
IC base 20 pin DIL 1 IC1
IC base 20 pin SIL 1 IC14
IC base 24 pin 300mil 1 IC15
IC base 84 pin PLCC 1 IC13
LCD display DMF5005N 1
Diode 1N4148 2 D2,D5
Schottky diode 1N5819 2 D4, D6
Schottky diode BAT54 2 D7, D8
Zener diode 13V 1 D1
Transzorbdiode BZW06-6V4B 1 D3
Transzorbdiode BZW06-17B 3 D9 - Dll
Crystal 8 MHz 1 Y1
Resistor 1K0 1% 0.5W 1 R8
Resistor 2K2 1% 0.5W 1 R9
Resistor 3K3 1% 0.5W 1 R13
Resistor 10K 1% 0.5W 3 R6, R10, Rll
Resistor 18K 1% 0.5W 1 R19
Resistor 22K 1% 0.5W 1 R12
Resistor 30K 1% 0.5W 1 R7
Resistor 40K 1% 0.5W 1 R1
Resistor 47K 1% 0.5W 3 R5, R14, R18
Resistor 80K 1% 0.5W 2 R3, R4
Resistor 10M 1% 0.5W 1 R2
Resistor OR 1 L4
PTC resistor MF-R030 Boums 1 R16
Potentiometer 50K 1-turn 1 P2
Potentiometer 10K 20 turn 1 P1
Resistor pack 5 x 2K2 1 RP3
Resistor pack 8 x 4K7 1 RP4
Resistor pack 8 x 10K 2 RP1, RP2
Cer. capacitor 22pF 50V 2 C1, C2
Multilay. X7R lnF 50V 1 C3
Multilay. X7R 4n7 50V 1 C4
Multilay. X7R 100nF 50V 9 C6 - Cll, C15, C16, C19
Electrolyte Capacitor
10µF 16V
1 C13
Electrolyte Capacitor
100µF 16V
6 C18, C23 - C27
Electrolyte Capacitor
10µF 30V
1 C28 - C30
RF coil 1.2mH 2 L2, L3
6
