COMPONENT PART TYPE/VALUE QTY. DIAGRAM REFERENCE
EMI Filter DSS306-91Y 28 F1-F18, F21, F22, F25 - F31
EMI Filter DSS710-D22 1 F19
EMI Filter DSS306-91F 9 F20, F23, F24, F32 - F34, F37 - F38
Battery contact FemaleS-G9312#0 1 J7
Header 2 pole 2 J6, J10
Phono-base CLIFF PHS2A 1 J8
D-sub 9p Male 90 degrees 1 J2
D-sub 28p Female 90 de-
grees
1 J1
Flat cable terminal 26P 2 J35, Jll
Flat cable plug 16P 1
Flat cable plug 20P 1
Box header 20P 1 J9
Connector 36-pol 1 TP101 -TP9
Flat cable 16 leads 280 mm
Flat cable 25 leads 200 mm
SENSOR BOARD
Sensor board AR-082 1
Volt. regulator MAX664CPA 1 IC107
A/D converter LTC1290CCN 1 IC104
Op.amp TL1413CN8 3 IC102, ICl10, IClll
Op.amp LT1012ACN8 1 IC101
V-ref. LT1027CCN8-5 1 IC105
Timer LMC555CN 1 IC106
Shift register 74HC589AN 1 ICl12
Shift register 74HC595AN 1 IC108
NAND port 74HC00AN 1 ICl13
Multiplexer 74HC4052P 1 ICl14
Diode 1N4148 3 Dlll - Dl13
Zener diode 5V1 4 D104 - D107
Schottky diode 1N5819 1 Dl14
Transzorb diode BZW06-10B 2 D101, D102
Transzorb diode BZW06-17B 3 D108 - Dl10
Resistor 47R 1% 0.5W 1 R184
Resistor 100R 1% 0.5W 1 R192
Resistor 499R 1% 0.5W 3 R131, R138, R139
Resistor 1K0 1% 0.5W 1 R129
Resistor 2K0 0.1% 0.5W 2 R121, R124
Resistor 3K16 0.1% 0.5W 1 R140
Resistor 3K3 1% 0.5W 1 R132
Resistor 3K74 1% 0.5W 1 R130
Resistor 3K9 0.1% 0.5W 16 R1245-R151, R153 - R159, R180,
R181
Resistor 4K7 0.1% 0.5W 1 R141
Resistor 5K36 1% 0.5W 2 R188, R193
Resistor 8K06 1% 0.5W 1 R109, Rl18
Resistor 10K 0.1% 0.5W 4 R122, R123, R125, R126
Resistor 10K 1% 0.5W 5 R128,R136,R137,R143,R190
Resistor 20K 0.1% 0.5W 3 R127, R142, R144
Resistor 20K 1% 0.5W 1 R135
Resistor 40K2 1% 0.5W 1 R134
Resistor 90K9 1% 0.5W 1 R191
Resistor 180K 1% 0.5W 2 R133, R189
Resistor 200K 0.1% 0.5W 2 R120, R187
Resistor 249K 0.1% 0.5W 16 R101 - R108, Rl10 - Rl17
Resistor 10M 1% 0.5W 3 R194 - R196
Resistor 0R 2 L102, L103
Resistor N.C. 1 Rl19
Power resistor 25R 1% 2 R185, R186
Potentiometer 1K 20-turn 1 P102
7
