METRON QA-45 User Manual

COMPONENT PART TYPE/VALUE QTY. DIAGRAM REFERENCE
Resistor 1K52 0.1% 0.5W 2 R21, R22
Resistor 1K8 1% 0.5W 1 R12
Resistor 2K 0.1% 0.5W 1 Rll
Resistor 10K 0.1% 0.5W 4 R9, R13, R,?.5, R28
Resistor 10K 1% 0.5W 3 R15, R24, R27
Resistor 20K 0.1% 0.5W 4 R8, R10, R14, R16
Resistor 24K 0.1% 0.5W 2 R17, R18
Resistor 30K 0.1% 0.5W 2 R26, R29
Resistor 249K 0.1% 0.5W 2 R19, R20
Multilay. X7R 100nF 50V 8 C1 - C5, C7, C8, C10
Electrolyte Capacitor
100µF 25V
1 C9
N.C. C6
RF coil 1.2mH 1 L1
Relay -B201 4 K1 - K4
Relay -B101 2 K5, K6
Connector 2x36-pol 1 J1
KK contact 4-pol 1 J4
Connector 36-pol 1 TP1 -TP6
9
