Slurry Pump
WH16AA1LA00EN_01E.DOC JAN 04-W08
Care and maintenance
3/3
9.4.3 Lubrication points
The pumps have two bearing lubrication points. See Figure 9.4.3-1.
Part Position Qty.(cc) Frequency Lubricant
Bearing cylinder
A
See
Table
9.4.2-1.
See Table
9.4.2-1.
SKF LGMT3 or equivalent -
see Table 9.4.1-1.
Motor and/or
gearbox (where
applicable)
– – –
See manufacturer’s instruction
manual.
A
Figure 9.4.3-1 Lubrication point diagram- Bearing greasing points (A)
