Slurry Pump
WH16AM1TAA0EN_02A.DOC JAN 04-W51
Care and maintenance
4/6
9.3 Tools and special equipment for service and maintenance
NOTE: THE FOLLOWING SPECIAL TOOLS ARE AVAILABLE FOR PUMPS WITH EITHER SINGLE, OR
DOUBLE, ADJUSTMENT FRAMES.
1. A special crank-handle to fit over the drive-shaft end diameter and locate the drive
key is advantageous when fitting the impeller to the shaft. See Dismantling and
Fitting the Hydraulic Parts, section 9.5.2.
Figure 9.3-1 Special crank handle
