Metso MM200 EHC-D User Manual

Slurry Pump
WH26MM1AAA0EN_03C.DOC JAN 04-W08
Spare parts
1/1
10.6 Toolkit
10.6.1
Standard tools
In addition to the special tools detailed in sub-section 9.3 and Table 10.6-2, and
installation tools and equipment detailed in sub-section 6.3, Table 10.6-1 lists a basic
toolkit for performing normal maintenance operations on the pump. A dial test indicator
may also be required to set bearing clearances – verify by reference to section 9.5.5.
Additional tools may also be listed in the motor installation and maintenance
documentation. Refer to Reference Publications, sub-section 11.2.
Table 10.6-1 Toolkit
Item Qty. Type Sizes
MM100 MM150 MM200 MM250 MM300 MM350 MM 400
1 1 Spanner AF
(mm)
19 22 24 30 36 36
2 1 Socket AF (mm) 17, 24 17, 19,
24, 27,
30
22, 24,
30, 36
24, 30,
36
19, 30,
36, 46
24, 30,
36, 46,
55
3 1 Torque wrench
(Nm range)
10 - 300 20 - 500
4 1 Adjustable
spanner (mm)
25 30 40
10.6.2 Special tools
Table 10.6-2 Special tools
Item Size Part No.
Crank Packing
extractor
Back-liner lifter Shaft extension
1
MM100
SA500244-M1
2
MM150
SA219594-M1
3
MM200
SA219595-M1
981865
N/A
4
MM250
SA219596-M1
N/A
SA501470-M1
5
MM300/
MM350
SA219598-M1 SA501471-M1
6
MM400
SA219598-M1
981607
SA501472-M1
