11 APPENDICES
11.1 Torque table
The following table gives the recommended torque values for tightening bolts and screws.
NOTE: ALL TORQUE VALUE TOLERANCES ARE ±5%.
TORQUE VALUES (Nm)
ITEM MM100 MM150 MM200 MM250 MM300 MM350 MM400
Case bolt (P4) 147 163 189 189 270 270
Casing clamp screw(P9) 147 163 189 189 270 270
Bearing frame
screw(P11)
163 163 177 189 338 338
Back-liner bolts(W19) 34 34 54 98 142 142
Housing clamp
screws(P16)
34 40 54 67 80 80
Tension screws(P23)
16 to 18 16 to 18 16 to 18 26 to 34 26 to 34 26 to 34
Saddle screws(P20) 34 40 54 54 108 108
End-cover screw(B5) 34 40 40 54 81 81
Outlet flange half-clamp
bolts NP16 (F3)
M8 (20)
M10 (40)
M12 (70)
M16 (170)
M16 (170)
M16 170)
Inlet flange half-clamp
bolts NP16 (F1)
M8 (20)
M12 (70)
M16 (170)
M16 (170)
M16 (170)
M16 (170)
