METTLER TOLEDO 2888 Deckmate Floor Scales Installation and Service Manual
(10/96)
Platform Assembly
Deckmate scales utilize a channel reinforced deck with “live” side
rails design, which provides mounting for the four load cells, protection
for the load cell cables, and mounting for the junction box. The platform
is available in mild steel or stainless steel with either tread or smooth plate
deck. The stainless steel platform with smooth plate deck has a glass bead
blast finish (see Figure 1-b).
Figure 1-b: Platform Assembly
DECK
DATA PLATE
JUNCTION BOX
LOAD CELL -- TYPICAL
EACH CORNER
SIDE RAILS
