METTLER TOLEDO 2888 Deckmate Floor Scales Installation and Service Manual
(10/96)
1-6
Portable Assembly
The support frame for the portable assembly provides support for the
2888 platform and the ability to easily move the platform from one
weighing location to another. (see Figure 1-d).
SCALE DECK
30 in (76.2 cm) x 30 in (76.2 cm)
INDICATOR MOUNTING
BRACKET
HANDLE
BATTERY PACK
MOUNTING BRACKET
INDICATOR COLUMN
RAMP ( 0PTIONAL)
PORTABLE FRAME
SWIVEL CASTER
EACH CORNER
4.38 in (11.12 cm) ---- WEIGHING HEIGHT
5.75 in (14.60 cm) ---- TRANSPORT HEIGHT
46.12 in
(117.14 cm)
33.62 in
85.40 cm
BUBBLE LEVEL
1.31 in (3.33 cm) toTop of Deck ----WEIGHING HEIGHT
Figure 1-d: Portable Platform
