Chapter 4: Optional Ramp Installation
Mode of Operation
(10/96)
4 Optional Ramp Installation
Model 2888 Deckmate ramps provide access from one or both ends of
the scale. Select which end(s) of the platform is to have a ramp
attachment.
The static platform ramps are installed after anchoring the support frame
to the floor. To install a ramp place the mating end of the ramp over the
ramp mounting bar (see figure 1-c). Check to make sure that the ramp is
stable. (Shim under the corners of the ramp if required)
The Portable Platform ramps are hinged to the support frame. This will
allow the ramps to be folded on top of the deck when the platform is
moved from one location to another. With the platform in the weighing
position and the ramps down in place, check to make sure that the ramps
are stable. (Shim under the corners of the ramp if required)
