Chapter 9: Reference Material
Reference Drawings
(10/96)
9 Reference Material
Reference
Drawings
Scale Static Portable
1000 lb / 500 kg TC202768 TC202769
Recommended Spare
Parts
Part Number Description
TB600529-1 500 lb Analog Load Cell
*14378800A Analog Junction Box PCB
TN200050 Load Pin
MZ0909000005 O - Ring
* May have a letter prefix
Load Cell Data
Model number: 745
NTEP certificate of conformance number: 92-108
Rated Capacity 500 lb
Maximum excitation voltage: 15 VDC or VAC rms
Recommended excitation voltage: 15 VDC
Full scale output: 2 mV/V
Input terminal resistance: 350 Ohm minimum
Output terminal resistance: 350 + 2 Ohms
Temperature range compensation: -10°C to +40°C (+14°F to +104°F)
Safe side load: 100% of full load cell rating
Safe overload: 150% of full load cell rating
